Gridview - How to pass value from datatable to MKB TimeSelector

In my asp.net + VB Gridview, I had bind several column from datatable into one single column of the gridview.

But I have no idea how to pass the time value from datatable to MKB TimeSelector in gridview and update. Please help. Thanks.

But I have no idea how to get those value when doing RowEditing & RowUpdating. Please help. Thanks.

The following is the VB code:

Protected Sub GridView1_RowEditing(ByVal sender As Object, ByVal e As GridViewEditEventArgs)
    'Set the edit index.
    Gridview1.EditIndex = e.NewEditIndex
    'Bind data to the GridView control.
    BindData()
End Sub

Protected Sub GridView1_RowCancelingEdit(ByVal sender As Object, ByVal e As GridViewCancelEditEventArgs)
    'Reset the edit index.
    Gridview1.EditIndex = -1
    'Bind data to the GridView control.
    BindData()
End Sub

Protected Sub GridView1_RowUpdating(ByVal sender As Object, ByVal e As GridViewUpdateEventArgs)
    'Retrieve the table from the session object.
    Dim dt = CType(Session("dt"), DataTable)

    'Update the values.
    Dim row = Gridview1.Rows(e.RowIndex)

    .............................

    'Reset the edit index.
    Gridview1.EditIndex = -1

    'Bind data to the GridView control.
    BindData()
End Sub

The following is the aspx code:

Private Sub CreateDataTable()

    Dim cmd As New System.Data.SqlClient.SqlCommand
    Dim sql As String
    Dim reader As System.Data.SqlClient.SqlDataReader
    Dim cmd3 As New System.Data.SqlClient.SqlCommand
    Dim sql3 As String
    Dim reader3 As System.Data.SqlClient.SqlDataReader

    Using conn2 As New System.Data.SqlClient.SqlConnection(ConfigurationManager.ConnectionStrings("XXXonnectionString").ConnectionString)
        conn2.Open()
        cmd.Connection = conn2

        sql = "SET DATEFORMAT dmy;SELECT * FROM XXXX "
        cmd.CommandText = sql
        reader = cmd.ExecuteReader()

        Dim TempStaffKey As Integer
        Dim TempPostKey As Integer
        Dim TempShiftDate As DateTime
        Dim TempStartTime As DateTime
        Dim TempEndTime As DateTime
        Dim TempSL As String
        Dim TempRosterKey As Integer
        Dim TempVL As String
        Dim TempML As String
        Dim TempPH As String
        Dim TempAPH As String
        Dim TempTOIL As String
        Dim TempOthers As String
        Dim TempShiftType As Integer
        Dim TempSubmittedBy As Integer

        Dim dt As New DataTable()
        dt.Columns.Add(New DataColumn("StaffName", GetType(String)))
        dt.Columns.Add(New DataColumn("PostCode", GetType(String)))
        dt.Columns.Add(New DataColumn("StaffKey", GetType(Int32)))
        dt.Columns.Add(New DataColumn("PostKey", GetType(Int32)))

        'Monday
        dt.Columns.Add(New DataColumn("Col1_RosterKey", GetType(Int32)))
        dt.Columns.Add(New DataColumn("Col1_ShiftDate", GetType(DateTime)))
        dt.Columns.Add(New DataColumn("Col1_StartTime", GetType(DateTime)))
        dt.Columns.Add(New DataColumn("Col1_EndTime", GetType(DateTime)))
        dt.Columns.Add(New DataColumn("Col1_SL", GetType(String)))
        dt.Columns.Add(New DataColumn("Col1_VL", GetType(String)))
        dt.Columns.Add(New DataColumn("Col1_ML", GetType(String)))
        dt.Columns.Add(New DataColumn("Col1_PH", GetType(String)))
        dt.Columns.Add(New DataColumn("Col1_APH", GetType(String)))
        dt.Columns.Add(New DataColumn("Col1_TOIL", GetType(String)))
        dt.Columns.Add(New DataColumn("Col1_Others", GetType(String)))
        dt.Columns.Add(New DataColumn("Col1_ShiftType", GetType(Int32)))
        dt.Columns.Add(New DataColumn("Col1_SubmittedBy", GetType(Int32)))

        Dim dr As DataRow

        While reader.Read()    '---For each row

            g_TempStaffKey = "0"
            TempStaffKey = reader("staff_key")   'will not null
            g_selectstaffkey = TempStaffKey
            g_selectpostkey = reader("post_key")
            g_selectstaffname = RTrim(reader("name_eng"))
            g_selectpostcode = RTrim(reader("post_code"))

            Using conn3 As New System.Data.SqlClient.SqlConnection(ConfigurationManager.ConnectionStrings("XXXConnectionString").ConnectionString)
                conn3.Open()
                cmd3.Connection = conn3
                sql3 = "SET DATEFORMAT dmy;SELECT * FROM xxx"
                cmd3.CommandText = sql3
                reader3 = cmd3.ExecuteReader()
                If reader3.Read() Then

                    TempStaffKey = reader3("staff_key")

                    If Not IsDBNull(reader3("post_key")) Then
                        TempPostKey = reader3("post_key")
                    End If

                    If Not IsDBNull(reader3("roster_key")) Then
                        TempRosterKey = reader3("roster_key")
                    End If

                    If Not IsDBNull(reader3("shift_date")) Then
                        TempShiftDate = Format(reader3("shift_date"), "dd/MM/yyyy")
                    End If

                    If Not IsDBNull(reader3("start_time")) Then
                        TempStartTime = Format(reader3("start_time"), "HH:mm")
                    End If

                    If Not IsDBNull(reader3("end_time")) Then
                        TempEndTime = Format(reader3("end_time"), "HH:mm")
                    End If

                    If Not IsDBNull(reader3("SL")) Then
                        TempSL = reader3("SL")
                    Else
                        TempSL = "0"
                    End If

                    If Not IsDBNull(reader3("VL")) Then
                        TempVL = reader3("VL")
                    Else
                        TempVL = "0"
                    End If

                    If Not IsDBNull(reader3("ML")) Then
                        TempML = reader3("ML")
                    Else
                        TempML = "0"
                    End If

                    If Not IsDBNull(reader3("PH")) Then
                        TempPH = reader3("PH")
                    Else
                        TempPH = "0"
                    End If

                    If Not IsDBNull(reader3("APH")) Then
                        TempAPH = reader3("APH")
                    Else
                        TempAPH = "0"
                    End If

                    If Not IsDBNull(reader3("TOIL")) Then
                        TempTOIL = reader3("TOIL")
                    Else
                        TempTOIL = "0"
                    End If

                    If Not IsDBNull(reader3("Others")) Then
                        TempOthers = reader3("Others")
                    Else
                        TempOthers = "null"
                    End If

                    If Not IsDBNull(reader3("shift_type")) Then
                        TempShiftType = reader3("shift_type")
                    End If

                    If Not IsDBNull(reader3("submitted_by")) Then
                        TempSubmittedBy = reader3("submitted_by")
                    End If

                    dr = dt.NewRow()

                    dr("StaffName") = g_selectstaffname
                    dr("PostCode") = g_selectpostcode
                    dr("StaffKey") = TempStaffKey
                    dr("PostKey") = TempPostKey

                    'Col1
                    If TempShiftDate = g_header1 Then
                        dr("Col1_RosterKey") = TempRosterKey
                        dr("Col1_ShiftDate") = TempShiftDate
                        dr("Col1_StartTime") = TempStartTime


                        dr("Col1_EndTime") = TempEndTime
                        dr("Col1_SL") = TempSL
                        dr("Col1_VL") = TempVL
                        dr("Col1_ML") = TempML
                        dr("Col1_PH") = TempPH
                        dr("Col1_APH") = TempAPH
                        dr("Col1_TOIL") = TempTOIL
                        dr("Col1_Others") = TempOthers
                        dr("Col1_ShiftType") = TempShiftType
                        dr("Col1_SubmittedBy") = TempSubmittedBy
                    End If

                End If
.................

                conn3.Close()
                reader3.Close()
            End Using
        End While

        Gridview1.DataSource = dt
        Gridview1.DataBind()

        'Persist the table in the Session object.
        Session("dt") = dt

        reader.Close()

    End Using

End Sub



<%@ Page Title="Input" Language="VB" MasterPageFile="~/MasterPage.master" AutoEventWireup="false" CodeFile="sd210.aspx.vb" Inherits="sd210" ValidateRequest="false"%>
<%@ Register Assembly="TimePicker" Namespace="MKB.TimePicker" TagPrefix="MKB" %>

<asp:Content ID="Content1" ContentPlaceHolderID="CPH1" Runat="Server">
<asp:ScriptManager ID="ScriptManager1" runat="server">
</asp:ScriptManager>
    <asp:SqlDataSource ID="SqlDataSource1" runat="server" ConnectionString="<%$ ConnectionStrings:hris_shiftdutyConnectionString %>"SelectCommand="set language english; SET DATEFORMAT dmy; select * from troster">
</asp:SqlDataSource>

    <asp:SqlDataSource ID="SqlDataSource2" runat="server" ConnectionString="<%$ ConnectionStrings:hris_shiftdutyConnectionString %>"
    SelectCommand="set language english; select * from tshift_type">
</asp:SqlDataSource>
<asp:Label ID="lb_login_name" runat="server"  Visible="false"  ></asp:Label>
<asp:Label ID="lb_login_staff_key" runat="server"  Visible="false"  ></asp:Label>
<asp:Label ID="lb_login_post_key" runat="server"  Visible="false"  ></asp:Label>
<asp:Label ID="lb_test" runat="server"  Visible="false"  ></asp:Label>

<asp:GridView ID="Gridview1" runat="server"
AutoGenerateColumns = "false" Font-Names = "Arial"
AutoGenerateEditButton="True"
Font-Size = "10pt" AlternatingRowStyle-BackColor = "#C2D69B"
AllowPaging ="true"
PageSize = "20" Caption = ""
onrowdatabound="GridView1_RowDataBound"
OnRowEditing="GridView1_RowEditing"
OnRowCancelingEdit="GridView1_RowCancelingEdit"
OnRowUpdating="GridView1_RowUpdating"
OnPageIndexChanging="GridView1_PageIndexChanging">

<HeaderStyle BackColor="#4A3C8C" Font-Bold="True" ForeColor="#F7F7F7" />
<Columns>
 <asp:BoundField DataField = "PostCode" HeaderText = "Post"  ReadOnly ="true" />
 <asp:BoundField DataField = "StaffName" HeaderText = "Name" ReadOnly ="true"  />

<asp:TemplateField HeaderText="Working<br>Time">
<ItemTemplate>
<asp:Label ID="lb1_rosterkey"  runat="server"  Text='<%#DataBinder.Eval(Container.DataItem, "Col1_RosterKey")%>'  Visible ="false" ></asp:Label>
<asp:BoundField DataField = "Col1_ShiftType" />
<MKB:TimeSelector ID="Col1_StartTime1" runat="server" DisplaySeconds="False" ReadOnly="true" MinuteIncrement="1" AmPm="AM" BorderColor="Silver"
                            Date="" Hour="07" Minute="0"  SelectedTimeFormat="Twelve"></MKB:TimeSelector>
<MKB:TimeSelector ID="Col1_EndTime1" runat="server" DisplaySeconds="False"  ReadOnly="true" MinuteIncrement="1" AmPm="PM" BorderColor="Silver"
                            Date="" Hour="07" Minute="0" SelectedTimeFormat="Twelve"></MKB:TimeSelector>

</ItemTemplate>
<EditItemTemplate>
<MKB:TimeSelector ID="Col1_StartTime1" runat="server" Displa开发者_JAVA技巧ySeconds="False"  MinuteIncrement="1" AmPm="AM" BorderColor="Silver"
                            Date="" Hour="07" Minute="0"  SelectedTimeFormat="Twelve"></MKB:TimeSelector>
<MKB:TimeSelector ID="Col1_EndTime1" runat="server" DisplaySeconds="False"  MinuteIncrement="1" AmPm="PM" BorderColor="Silver"
                            Date="" Hour="07" Minute="0" SelectedTimeFormat="Twelve"></MKB:TimeSelector>
</EditItemTemplate>

</asp:TemplateField>

<asp:TemplateField HeaderText="Leave/TOIL">
<ItemTemplate>
<asp:CheckBox
ID="cb1_VL" Enabled="false" Text="VL"
runat="server"
Checked=<%#DataBinder.Eval(Container.DataItem, "Col1_VL")%> />
<asp:CheckBox
ID="cb1_SL" Enabled="false" Text="SL"
runat="server"
Checked=<%#DataBinder.Eval(Container.DataItem, "Col1_SL")%> />
<asp:CheckBox
ID="cb1_ML" Enabled="false" Text="ML"
runat="server"
Checked=<%#DataBinder.Eval(Container.DataItem, "Col1_ML")%> />
<asp:CheckBox
ID="cb1_PH" Enabled="false" Text="PH"
runat="server"
Checked=<%#DataBinder.Eval(Container.DataItem, "Col1_PH")%> />
<asp:CheckBox
ID="cb1_APH" Enabled="false" Text="APH"
runat="server"
Checked=<%#DataBinder.Eval(Container.DataItem, "Col1_APH")%> />
<asp:CheckBox
ID="cb1_TOIL" Enabled="false" Text="TOIL"
runat="server"
Checked=<%#DataBinder.Eval(Container.DataItem, "Col1_TOIL")%> />
<br />
<%#DataBinder.Eval(Container.DataItem, "Col1_Others")%>
</ItemTemplate>
<EditItemTemplate>

<asp:CheckBox
ID="cb1_VL" Text="VL"
runat="server"
Checked=<%#DataBinder.Eval(Container.DataItem, "Col1_VL")%> />
<asp:CheckBox
ID="cb1_SL"  Text="SL"
runat="server"
Checked=<%#DataBinder.Eval(Container.DataItem, "Col1_SL")%> />
<asp:CheckBox
ID="cb1_ML"  Text="ML"
runat="server"
Checked=<%#DataBinder.Eval(Container.DataItem, "Col1_ML")%> />
<asp:CheckBox
ID="cb1_PH"  Text="PH"
runat="server"
Checked=<%#DataBinder.Eval(Container.DataItem, "Col1_PH")%> />
<asp:CheckBox
ID="cb1_APH"  Text="APH"
runat="server"
Checked=<%#DataBinder.Eval(Container.DataItem, "Col1_APH")%> />
<asp:CheckBox
ID="cb1_TOIL" Text="TOIL"
runat="server"
Checked=<%#DataBinder.Eval(Container.DataItem, "Col1_TOIL")%> />
<asp:TextBox ID="tb1_Others" runat="server" Width="50" Text='<%#DataBinder.Eval(Container.DataItem, "Col1_Others") %>'></asp:TextBox>
</EditItemTemplate>
</asp:TemplateField>

............

</Columns>
</asp:GridView>
</asp:Content>

Joe

Here is a way to set your TimePicker's value when GridView is in Edit-Mode:

GridView1_DataBound(ByVal sender As Object, ByVal e As GridViewRowEventArgs) Handles GridView1.RowDataBound
    If e.Row.RowType = DataControlRowType.DataRow AndAlso e.Row.RowState = DataControlRowState.Edit Then
        Dim row = DirectCast(e.Row.DataItem, DataRowView).Row
        Dim Col1_StartTime1 = DirectCast(e.Row.FindControl("Col1_StartTime1"), MKB.TimePicker)
        'set the TimePicker's Value here according to the Time-Value in the DataRow'
    End If
End Sub

Here is a way to get the values in RowUpdating:

Private Sub GridView1_RowUpdating(ByVal sender As Object, ByVal e As GridViewUpdateEventArgs) Handles GridView1.RowUpdating
    Dim dt = CType(Session("dt"), DataTable)
    'Update the values.
    Dim row = GridView1.Rows(e.RowIndex)
    dt.Rows(row.DataItemIndex)("PostCode") = (CType((row.Cells(1).Controls(0)), TextBox)).Text
    dt.Rows(row.DataItemIndex)("StaffName") = (CType((row.Cells(2).Controls(0)), TextBox)).Text
    Dim Col1_StartTime1 = DirectCast(row.FindControl("Col1_StartTime1"),TimeSelector)
    dt.Rows(row.DataItemIndex)("WorkingTime") = Col1_StartTime1.Value
    '.....'

    'Bind data to the GridView control.
    BindData()
  End Sub
